0.5mm Seamless Round Metal Tube Copper And Copper Alloys B2

Name: 05mm Seamless Round Metal Tube Copper And Copper Alloys B2
Brand: zhongxin
Price: 8 USD

Buy cheap 0.5mm Seamless Round Metal Tube Copper And Copper Alloys B2 product

Brand Name : zhongxin

Model Number : Inconel 8255

Certification : ISO, EN, MTC

Place of Origin : CHINA

MOQ : 1 PCS

Price : 8USD ---16 USD / kg

Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 4000 MT PER week

Delivery Time : 5-25 Days

Packaging Details : Standard export seaworthy package or As required

Standard : ASTM B 466

Alternate name : Alloy B2 , Alloy B3 , Hastelloy alloy

Outer diameter : 4 to 219mm

Wall thickness : 0.5mm to 20mm

Form or shape : Round , flat , Square ,Hex, rectangular

Pipe End : Plain End, Beveled End, Treaded.

Finish : Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF

Technique : Cold rolled , Hot rolled

Application : Heat resistant , Chemical resistant application

Trade name : cupro nickel Pipe

Contact Now

ASTM B 466 90/10 Schedule 40 Copper Nickel Cold Brushed Seamless Round Pipe For Marine Hardware Seawater Piping System

ASTM B 466 90/10 Schedule 40 Copper Nickel Cold Brushed Seamless Round Pipe For Marine Hardware Seawater Piping System overview

The Molecular Formula of Copper Nickel Pipe is ‎CuNi. Copper nickel seamless pipe has a Density of 0.323 lb/in³ (8.94 g/cm3). The Poisson’s Ratio of Copper nickel piping (C71500 annealed) is 0.325. Copper nickel pipe specifications are, is that they can be obtained in various types of thicknesses, specifications and grades, as per the need. Because of their resistance to corrosion, Copper Nickel Alloy Pipe, also known as Cupronickel pipe has tremendous use in saltwater environments. It is in great demand for use in fish cages used for aquaculture, in desalination units and in sea water pipe-work. It is also used in offshore platforms, in boat hull risers, desalination plants, marine hardware used in boats, hydraulic lines and in underwater fencing. The Elongation at Break of Copper nickel (rolled-H04 for flat products/hard drawn-H80 for tubing), is 11.00% and its Elongation at Break (annealed), is 40%.

ASTM B 466 90/10 Schedule 40 Copper Nickel Cold Brushed Seamless Round Pipe For Marine Hardware Seawater Piping System Specification and Dimension Rranges

ASTM B 466 90/10 Schedule 40 Copper Nickel Cold Brushed Seamless Round Pipe

Copper Nickel Pipe specifications
COPPER NICKEL	Alloy	ISO	BSI	BS EN	UNS	KS
Copper Nickel 90/10 Pipe (Kunifer 10)	Cu-Ni 90/10	CuNi10Fe1Mn	CN102	CW352H	C70600	C7060
Copper Nickel 70/30 Pipe (Kunifer 30)	Cu-Ni 70/30	CuNi30Mn1Fe	CN107	CW354H	C71500	C7150
Copper Nickel 66/2/2 Pipe (Yorcoron)		CuNi30Fe2Mn2	CN108	CW353H	C71640	C7164

Copper Nickel Cold Brushed Seamless Round Pipe Dimension :

Copper Nickel Pipes Specifications	ASTM B 466 ASME SB 466 / ASTM B 467 ASME SB 467
Cu-Ni Seamless Pipes size	4 to 219mm W. T.: 0.5 to 20mm
Welded Pipe size	5.0 mm - 1219.2 mm
Specialized in	Large Diameter Cupro Nickel Pipes
Schedule	SCH5, SCH10, SCH40, STD, SCH80, SCH160
Finish	Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
Form	Round, Square, Hollow, Rectangular, Hydraulic, Straight Pipes Etc.
Length	Single Random, Double Random & Cut Length.
Copper Nickel Pipe End	Plain End, Beveled End, Treaded.
Marking	All Cu-Ni Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Material Test Certificates (MTC)	Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
We can also cut, thread, and groove Cu-Ni Pipes to meet your specifications

ASTM B 466 90/10 Schedule 40 Copper Nickel Cold Brushed Seamless Round Pipe For Marine Hardware Seawater Piping SystemApplication

COPPER NICKEL PIPE APPLICATIONS

Marine hardware
Desalination
Seawater piping systems
Cooling loops
Pipe nipples

ASTM B 466 90/10 Schedule 40 Copper Nickel Cold Brushed Seamless Round Pipe For Marine Hardware Seawater Piping System Package

0.5mm Seamless Round Metal Tube Copper And Copper Alloys B2

FAQ

Q: Would you provide samples For free?

A: Yes . with on stock specification We provide samples For Free . Freight charge collect

Q: What information should i provide to source for the right products ?

A: Material grade, width, thickness, coating and Purchase quantity , Expected lead time ,etc

Q: What are the shipping ports?

A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you

can choose other ports according to your needs.

Q: About product prices?

A:Prices vary from period to period due to cyclical changes in the price of raw materials.

Q: How long does your delivery time take?

A: In general, our delivery time is within 5-45 days, and may be delayed if the demand is extremely

large or special circumstances occur.

Q: Can I visit your location?

A: Of course, we welcome customers from all over the world to visit our factory. However, some

of the plants are not open to the public.

Q: Does the product have quality inspection before loading?

A: Of course, all our products are strictly tested for quality before packaging, and unqualified

products will be destroyed.

Q: How to pack the products?

A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation

wooden pallet. It can effectively protect products from corrosion during ocean transportation.

Q: What is your working time?

A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00,

we will reply to your inquiry during the next working day.

Hastelloy B3 tubes equivalent grades

Hastelloy B3 tubes equivalent grades are UNS N10675 and WERKSTOFF NR. 2.4600. The Chemical Composition of Hastelloy B3 is Titanium, Ti 0.2 max, Cobalt, Co 3 max, Iron, Fe 1-3, Zirconium, Zr 0.1 max, Copper, Cu 0.2 max, Sulfur, S 0.01 max, Manganese, Mn 3 max, Vanadium, V 0.2 max, Nickel, Ni 65 min, Niobium, Nb 0.2 max, Carbon, C 0.01 max, Chromium, Cr 1-3, Molybdenum, Mo 27-32, Tantalum, Ta 0.2 max, Tungsten, W 3 max, Phosphorus, P 0.03 max and Aluminum, Al 0.5 max. The Density of Hastelloy B3 is 0.333 lb/in³ (9.22 g/cc).
